Advanced PC mould starchless Jelly candy depositing machine – High Efficiency, Zero Starch Residue

Capacity: approx. 150kgs/h

Model :SJD150

The processing line is an advanced  PC mould starchless Jelly candy line, it can make different sizes of gelatin or pectin based soft candies(QQ candies) . It is an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.It can make with flat 2D mould or 3D moulds, it based on customer specific requirement .

A: Batch-wise cooking system

YINRICH’s Batch wise jelly mass cooking system offers a feeding ,cooking and mixing of raw materials for all type of continuous jelly candy production.

●Full stainless steel SUS304 made;

●Flexible: Design and construction of the cooking and mixing for preparing all types of jelly mass, such as pectin , galantine, agar-agar, starch, gum Arabic, etc.)

●Compact and modular in construction and features central connections for services(steam, air, water, electricity) resulting in a short start-up time.

B: Flavor, color, acid dosing and mixing system

Accurate metering system with plunger type pump driven by a common variable speed unit for the injection of the liquid additives(flavor, color, and acid)The additives are thoroughly mixed into the cooked mass by jacket stainless inline static mixer; In FCA system , it ensures that the end product will always be of a consistent and high quality; Compact design, and fully automatic operation.

C: Depositing and cooling section

●Underband Servo-drive designed depositer : All drive components are mounted on the machine(underband) rather than on the depositing head;

●The unique design is in compact and simple, which can  reduce the movement  inertia  and weight of the depositing head , thus it can achieve higher the depositor’s running speed to maximise output
