Relying on advanced technology, excellent production capabilities, and perfect service, Yinrich Technology takes the lead in the industry now and spreads our Yinrich Technology all over the world. Together with our products, our services are also supplied to be the highest-level. chocolate factory machine We have professional employees who have years of experience in the industry. It is them that provides high-quality services for customers all over the world. If you have any questions about our new product chocolate factory machine or want to know more about our company, feel free to contact us. Our professionals would love to help you at any time.In order to offer safe dehydrated foods, Yinrich Technology is produced conforming to high levels of hygienic standards. This production process is inspected strictly by the quality control department who all think highly of food quality.

chocolate mould line have different models with different  capacity.

Main Equipment list:

Appendix:  TECHNICAL SPECIFICATIONS FOR EACH EQUIPMENT:

1. OIL MELTING OVEN

Technical specifications:

Oil melting capacity: 2 x120=240kgs

Oil melting time: 30~60min

Heating method: Steam and power heating

Oil melting temperature: 40~65C

Dimension: 1300 x 650 x1000mm

2. SUGAR GRINDER:

Technical specifications:

Main drive motor power: 7.5KW

Feeding motor power: 1.5KW

Main drive speed: 3800 rpm

Feeding drive speed:280rpm

Dimension: 1240 x 960 x 1730mm

3. CONCH

Model: JMJ500

Max. capacity: 500liter

Fineness :20~25um

Main drive speed: 33rpm

Fine milling time: 16~22 hours

Power: 15KW

Dimension: 2000 x 1860 x 1250mm

   Model: JMJ1000

Max. capacity: 1000liter

Fineness :20~25um

Main drive speed: 33rpm

Fine milling time: 14~22 hours

Power: 22KW

Dimension: 2700 x 1350 x 1800mm

4. WARM KEEPING TANK

Model:BWG500

Max. capacity: 500liter

Main drive speed: 23.5 rpm

Power: 1.5 KW

Dimension: dia.1000 x 1380mm

Model:BWG1000

Max. capacity: 1000liter

Main drive speed: 24 rpm

Power: 2.2KW

Dimension: dia.1250 x 1850mm

5. CHOCALATE DEPOSITER WITH COOLING TUNNEL(one head version)

Model: QJ150(old)

Technical specifications:

Production capacity: 0.8~2.5tons/h

Power: 21KW

Refrigerator ‘s capacity: 15000~21800kcal/h

Dimension:15330 x1210 x 2200mm

Pieces of mould plates: 220 pcs

6. CHOCALATE TRANSPORTING PUMP

Model:SJB32

Motor power: 1.5KW

Main drive speed:127rpm

Capacity: 32liter/min

Length of Pressure: 2m

Dimension: 800 x 390 x 350mm

DELIVERY DATE:

Within 60 days upon the receipt of the down payment

DELIVERY:

Ex. Our Works at Shanghai, China

TERMS OF PAYMENT:

40%  by T/T as the down payment, the balance of 60% shall be pay before shipment.

OTHERS:

Testing & training:

The plant layout design, assembling and installation, start-up and local team training will be FREE at no cost. But the buyer should be responsible for the round-air tickets, local transportation, board & lodging ,and US$60.-/day/person for the pocket money to our technicians. The testing people will be two persons, and will cost 20~30 days.

Utilities:

The buyer should prepare sufficient electric power, water, steam and compressed air supplies which are suitable to be connected to our machinery before the arrival of our machinery.

WARRANTY:

The seller guarantee the quality of the products for 12 months since the date of installation . During the warranty period, any problems/defaults happen on the hard parts of the machinery ,the seller will replace the parts or send the technicians to go to the buyer’s site for repairing and maintenance at FREE. If the defaults are aroused by the defaulted operations of the buyer, or the buyer need the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
