Quality Chocolate Moulding Line - PLC Controlled & Various Products
The QJ series chocolate moulding line can continuously produce various kinds of chocolate products. It is a PLC controlled machine which consists of mould heating, depositing, vibrating, cooling, de-moulding and etc.. It can produce out good quality chocolate products such as “two color”, “ central filling”, and Pure solid chocolate products.
Product advantages
This Quality Chocolate Moulding Line offers precise and efficient production capabilities through its PLC control system. With the ability to create a variety of chocolate products, this machine ensures versatility and flexibility for your production needs. Its advanced technology and customizable features guarantee consistent and high-quality results every time.
We serve
We serve by providing a high-quality Chocolate Moulding Line that is PLC controlled and capable of producing various chocolate products. Our state-of-the-art technology ensures precision and efficiency, allowing you to create a wide range of delicious treats with ease. Whether you are a small artisanal chocolatier or a large-scale manufacturer, our moulding line is designed to meet your production needs. With a focus on quality and innovation, we aim to serve you by delivering a reliable and versatile solution that will enhance your chocolate-making process. Trust us to provide the tools you need to elevate your sweet creations to the next level.
Enterprise core strength
At our company, we serve top-quality chocolate moulding lines that are PLC controlled and can produce a variety of delicious products. Our focus on precision engineering and innovative technology ensures that each machine is reliable and efficient. With our dedication to customer satisfaction, we provide excellent after-sales support and training to ensure smooth operation. Whether you are a small artisanal chocolatier or a large-scale producer, we have the perfect solution for your chocolate moulding needs. Trust us to serve you with the best equipment and service in the industry. Choose our products and experience the difference in quality and performance.
chocolate mould line have different models with different capacity.
Main Equipment list:
| Item | Equipment | specification |
| 1. | HOT WATER CIRCULATING TANK | |
| 2. | OIL MELTING OVE | RYG-30 |
| 3. | SUGAR GRINDER | FTY250 |
| 4. | CONCH | JMJ50 |
| 5. | WARM KEEPING TANK | BWG500 |
| 6. | Chocolate moulding plant(one shot head) (INCLUDING THE COOLING TUNNEL) | QJ150 |
| 7. | TRANSPORTING PUMP | SJB32 |
| 8. | CONTROLLE | |
| 9 | MOULDS | |
| 10 | CONNECTING PIPES &VALVES | |
| 11 | packing machine | BM280 |
Appendix: TECHNICAL SPECIFICATIONS FOR EACH EQUIPMENT:
1. OIL MELTING OVEN
Technical specifications:
Oil melting capacity: 2 x120=240kgs
Oil melting time: 30~60min
Heating method: Steam and power heating
Oil melting temperature: 40~65C
Dimension: 1300 x 650 x1000mm
2. SUGAR GRINDER:
Technical specifications:
Main drive motor power: 7.5KW
Feeding motor power: 1.5KW
Main drive speed: 3800 rpm
Feeding drive speed:280rpm
Dimension: 1240 x 960 x 1730mm
3. CONCH
Model: JMJ500
Max. capacity: 500liter
Fineness :20~25um
Main drive speed: 33rpm
Fine milling time: 16~22 hours
Power: 15KW
Dimension: 2000 x 1860 x 1250mm
Model: JMJ1000
Max. capacity: 1000liter
Fineness :20~25um
Main drive speed: 33rpm
Fine milling time: 14~22 hours
Power: 22KW
Dimension: 2700 x 1350 x 1800mm
4. WARM KEEPING TANK
Model:BWG500
Max. capacity: 500liter
Main drive speed: 23.5 rpm
Power: 1.5 KW
Dimension: dia.1000 x 1380mm
Model:BWG1000
Max. capacity: 1000liter
Main drive speed: 24 rpm
Power: 2.2KW
Dimension: dia.1250 x 1850mm
5. CHOCALATE DEPOSITER WITH COOLING TUNNEL(one head version)
Model: QJ150(old)
Technical specifications:
Production capacity: 0.8~2.5tons/h
Power: 21KW
Refrigerator ‘s capacity: 15000~21800kcal/h
Dimension:15330 x1210 x 2200mm
Pieces of mould plates: 220 pcs
6. CHOCALATE TRANSPORTING PUMP
Model:SJB32
Motor power: 1.5KW
Main drive speed:127rpm
Capacity: 32liter/min
Length of Pressure: 2m
Dimension: 800 x 390 x 350mm
DELIVERY DATE:
Within 60 days upon the receipt of the down payment
DELIVERY:
Ex. Our Works at Shanghai, China
TERMS OF PAYMENT:
40% by T/T as the down payment, the balance of 60% shall be pay before shipment.
OTHERS:
Testing & training:
The plant layout design, assembling and installation, start-up and local team training will be FREE at no cost. But the buyer should be responsible for the round-air tickets, local transportation, board & lodging ,and US$60.-/day/person for the pocket money to our technicians. The testing people will be two persons, and will cost 20~30 days.
Utilities:
The buyer should prepare sufficient electric power, water, steam and compressed air supplies which are suitable to be connected to our machinery before the arrival of our machinery.
WARRANTY:
The seller guarantee the quality of the products for 12 months since the date of installation . During the warranty period, any problems/defaults happen on the hard parts of the machinery ,the seller will replace the parts or send the technicians to go to the buyer’s site for repairing and maintenance at FREE. If the defaults are aroused by the defaulted operations of the buyer, or the buyer need the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
