Commercial Chocolate Moulding Line: PLC Controlled for Quality Production
The QJ series chocolate moulding line can continuously produce various kinds of chocolate products. It is a PLC controlled machine which consists of mould heating, depositing, vibrating, cooling, de-moulding and etc.. It can produce out good quality chocolate products such as “two color”, “ central filling”, and Pure solid chocolate products.
Product features
This commercial chocolate moulding line is equipped with PLC control for precise and quality production of chocolates. Its core attributes include automated production processes and high efficiency, while its extended attributes feature customizable mould designs and easy maintenance. The value attributes of this equipment lie in its ability to produce consistent and professional-quality chocolates, making it a must-have for any commercial chocolate making operation.
Team strength
At our company, our team strength lies in our collective expertise and dedication to producing quality chocolate moulding lines. From our skilled engineers and technicians who design and maintain our PLC controlled machines to our production team who ensures each unit meets our high standards, every member plays a crucial role in delivering top-notch equipment for our customers. Our strong team collaboration allows us to innovate, troubleshoot, and continuously improve our products for optimal performance and customer satisfaction. Trust in our team's commitment to excellence for a reliable and efficient chocolate moulding line solution.
Enterprise core strength
At the heart of our commercial chocolate moulding line is a strong and cohesive team dedicated to ensuring quality production. Our team comprises skilled technicians and engineers who work together seamlessly to maintain and operate the PLC controlled machinery. Their expertise and attention to detail guarantee consistent and precise moulding of chocolate products, meeting the highest standards of quality for our customers. With a shared commitment to excellence and innovation, our team is always striving to improve and enhance our processes to deliver top-of-the-line chocolate moulding solutions. Trust in our team's strength to elevate your production capabilities.
chocolate mould line have different models with different capacity.
Main Equipment list:
| Item | Equipment | specification |
| 1. | HOT WATER CIRCULATING TANK | |
| 2. | OIL MELTING OVE | RYG-30 |
| 3. | SUGAR GRINDER | FTY250 |
| 4. | CONCH | JMJ50 |
| 5. | WARM KEEPING TANK | BWG500 |
| 6. | Chocolate moulding plant(one shot head) (INCLUDING THE COOLING TUNNEL) | QJ150 |
| 7. | TRANSPORTING PUMP | SJB32 |
| 8. | CONTROLLE | |
| 9 | MOULDS | |
| 10 | CONNECTING PIPES &VALVES | |
| 11 | packing machine | BM280 |
Appendix: TECHNICAL SPECIFICATIONS FOR EACH EQUIPMENT:
1. OIL MELTING OVEN
Technical specifications:
Oil melting capacity: 2 x120=240kgs
Oil melting time: 30~60min
Heating method: Steam and power heating
Oil melting temperature: 40~65C
Dimension: 1300 x 650 x1000mm
2. SUGAR GRINDER:
Technical specifications:
Main drive motor power: 7.5KW
Feeding motor power: 1.5KW
Main drive speed: 3800 rpm
Feeding drive speed:280rpm
Dimension: 1240 x 960 x 1730mm
3. CONCH
Model: JMJ500
Max. capacity: 500liter
Fineness :20~25um
Main drive speed: 33rpm
Fine milling time: 16~22 hours
Power: 15KW
Dimension: 2000 x 1860 x 1250mm
Model: JMJ1000
Max. capacity: 1000liter
Fineness :20~25um
Main drive speed: 33rpm
Fine milling time: 14~22 hours
Power: 22KW
Dimension: 2700 x 1350 x 1800mm
4. WARM KEEPING TANK
Model:BWG500
Max. capacity: 500liter
Main drive speed: 23.5 rpm
Power: 1.5 KW
Dimension: dia.1000 x 1380mm
Model:BWG1000
Max. capacity: 1000liter
Main drive speed: 24 rpm
Power: 2.2KW
Dimension: dia.1250 x 1850mm
5. CHOCALATE DEPOSITER WITH COOLING TUNNEL(one head version)
Model: QJ150(old)
Technical specifications:
Production capacity: 0.8~2.5tons/h
Power: 21KW
Refrigerator ‘s capacity: 15000~21800kcal/h
Dimension:15330 x1210 x 2200mm
Pieces of mould plates: 220 pcs
6. CHOCALATE TRANSPORTING PUMP
Model:SJB32
Motor power: 1.5KW
Main drive speed:127rpm
Capacity: 32liter/min
Length of Pressure: 2m
Dimension: 800 x 390 x 350mm
DELIVERY DATE:
Within 60 days upon the receipt of the down payment
DELIVERY:
Ex. Our Works at Shanghai, China
TERMS OF PAYMENT:
40% by T/T as the down payment, the balance of 60% shall be pay before shipment.
OTHERS:
Testing & training:
The plant layout design, assembling and installation, start-up and local team training will be FREE at no cost. But the buyer should be responsible for the round-air tickets, local transportation, board & lodging ,and US$60.-/day/person for the pocket money to our technicians. The testing people will be two persons, and will cost 20~30 days.
Utilities:
The buyer should prepare sufficient electric power, water, steam and compressed air supplies which are suitable to be connected to our machinery before the arrival of our machinery.
WARRANTY:
The seller guarantee the quality of the products for 12 months since the date of installation . During the warranty period, any problems/defaults happen on the hard parts of the machinery ,the seller will replace the parts or send the technicians to go to the buyer’s site for repairing and maintenance at FREE. If the defaults are aroused by the defaulted operations of the buyer, or the buyer need the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
