1.FEATURES:

This cookie capper can be connected to the outlet conveyor of the biscuit plant, and it can automatically align, deposit and cap . Various types of soft and hard biscuits ,cakes can be processed .

The cakes or biscuits are automatically transferred from your exiting conveyor to the in- feed of the machine( or via a Biscuit magazine feeder and indexing system). The machine then aligns, accumulates, synchronizes the products, deposits an accurate amount of filling, and then caps the top onto the products. The sandwiches are then automatically transported to the wrapping machine, or to an enrobing machine for further process.

The machine consists of:

1)Biscuit or cookies infeed section/ or biscuit magazine feeder;

2)Flip-slide section (optional) ;

3)Depositing manifold(plain, center-filling, side-by side etc, as optional);

4) Capper;

5)PLC controller

2.Main Technical Specifications:

Depositing speed: 20~25 times/min

Capping speed:   40~50 capping /min

Depositing heads: as per the customer’s

Power: 380V/25KW

Dimension: L:8000 xW: 400 x H:1600mm

3. Products can be made on the plant:

4.Machine photo shows

Cookie Capper (Sandwich Machine) is our flagship machine, which can provide turnkey and highly flexible solutions for global customers, welcome to consult

Cookie Capper (Sandwich Machine) includes:

1) Cookie storage

2) biscuit indexing device

3) Storage manifold (plain, centre-fill, side-by-side, etc., optional)

4) Top biscuit placement device

5) Chocolate coating system, aerated chocolate;

advantage:

-Suitable for filling, capping and capping of various biscuits or cakes;

-PLC servo control, high speed capability;

- Can be connected with biscuit factory conveyor;

- Precise deposition on biscuits;

Made of food grade stainless steel 304
