Cov kab ua pwm chocolate QJ series tuaj yeem tsim ntau yam khoom chocolate tas li. Nws yog lub tshuab PLC tswj uas muaj pwm cua sov, tso, co, txias, tshem pwm thiab lwm yam. Nws tuaj yeem tsim cov khoom chocolate zoo xws li "ob xim", "central filling", thiab cov khoom chocolate ntshiab.
Tau teeb tsa ntau xyoo dhau los, Yinrich Technology yog ib lub chaw tsim khoom tshaj lij thiab kuj yog ib lub chaw muag khoom uas muaj peev xwm loj hauv kev tsim khoom, tsim qauv, thiab R & D. Lub tshuab ua chocolate Hoobkas Tau mob siab rau kev tsim khoom thiab kev txhim kho kev pabcuam zoo, peb tau tsim kom muaj lub koob npe nrov hauv kev lag luam. Peb cog lus tias yuav muab kev pabcuam sai thiab kev tshaj lij rau txhua tus neeg siv khoom thoob plaws ntiaj teb uas suav nrog kev pabcuam ua ntej muag, muag khoom, thiab tom qab muag. Txawm koj nyob qhov twg lossis koj ua lag luam dab tsi, peb xav pab koj daws txhua yam teeb meem. Yog tias koj xav paub ntau ntxiv txog peb lub tshuab ua chocolate Hoobkas khoom tshiab lossis peb lub tuam txhab, thov hu rau peb. Cov khoom ua haujlwm yuav luag tsis muaj suab nrov thaum lub sijhawm tag nrho cov txheej txheem dehydration. Tus qauv tsim ua rau tag nrho lub cev ntawm cov khoom kom nyob twj ywm thiab ruaj khov.
kab pwm chocolate muaj cov qauv sib txawv nrog lub peev xwm sib txawv.
Daim ntawv teev cov khoom siv tseem ceeb:
| Khoom | Cov khoom siv | cov lus qhia tshwj xeeb |
| 1. | HOT WATER CIRCULATING TANK | |
| 2. | OIL MELTING OVE | RYG-30 |
| 3. | LUB TSHUAB GRINDER QAB ZIB | FTY250 |
| 4. | CONCH | JMJ50 |
| 5. | WARM KEEPING TANK | BWG500 |
| 6. | Lub Hoobkas Ua Chocolate Moulding (Ib Lub Taub Hau) (INCLUDING THE COOLING TUNNEL) | QJ150 |
| 7. | TRANSPORTING PUMP | SJB32 |
| 8. | CONTROLLE | |
| 9 | COV MOLDS | |
| 10 | TXUAS COV YEEB & COV VALVES | |
| 11 | tshuab ntim khoom | BM280 |
Cov Lus Qhia Ntxiv: COV LUS QHIA TXOG TXHUA LUB CUAB YEEJ:
1. Qhov cub roj yaj
Cov lus qhia txog kev siv:
Muaj peev xwm yaj roj: 2 x120 = 240kgs
Lub sijhawm yaj roj: 30 ~ 60 feeb
Txoj kev cua sov: Chav thiab cua sov fais fab
Kub yaj roj: 40 ~ 65C
Qhov Loj: 1300 x 650 x 1000mm
2. LUB TSHUAB GRINDER QAB ZIB:
Cov lus qhia txog kev siv:
Lub zog tsav tsheb tseem ceeb: 7.5KW
Lub zog tsav tsheb pub mis: 1.5KW
Lub zog tsav tseem ceeb: 3800 rpm
Kev tsav tsheb pub ceev: 280rpm
Qhov Loj: 1240 x 960 x 1730mm
3. CONCH
Qauv: JMJ500
Muaj peev xwm ntau tshaj plaws: 500 litres
Qhov zoo: 20 ~ 25um
Lub ntsiab tsav ceev: 33rpm
Lub sijhawm ua kom zoo: 16 ~ 22 teev
Lub zog: 15KW
Qhov Loj: 2000 x 1860 x 1250mm
Qauv: JMJ1000
Maximum peev xwm: 1000 litres
Qhov zoo: 20 ~ 25um
Lub ntsiab tsav ceev: 33rpm
Lub sijhawm ua kom zoo: 14 ~ 22 teev
Lub zog: 22KW
Qhov Loj: 2700 x 1350 x 1800mm
4. LUB TSO CIA KOM SOV
Qauv: BWG500
Muaj peev xwm ntau tshaj plaws: 500 litres
Lub zog tsav tseem ceeb: 23.5 rpm
Lub zog: 1.5 KW
Qhov Loj: dia.1000 x 1380mm
Qauv: BWG1000
Maximum peev xwm: 1000 litres
Lub zog tsav tseem ceeb: 24 rpm
Lub zog: 2.2KW
Qhov Loj: dia.1250 x 1850mm
5. CHOCALATE DEPOSITER NROG COOLING TUNNEL (ib lub taub hau version)
Qauv: QJ150 (laus)
Cov lus qhia txog kev siv:
Muaj peev xwm ntau lawm: 0.8 ~ 2.5tons / h
Lub zog: 21KW
Lub tub yees lub peev xwm: 15000 ~ 21800kcal / h
Qhov Loj: 15330 x1210 x 2200mm
Cov phaj pwm: 220 pcs
6. Twj Tso Kua Chocolate
Qauv: SJB32
Lub zog tsav tsheb: 1.5KW
Lub ntsiab tsav ceev: 127rpm
Peev Xwm: 32liter/min
Qhov Ntev Ntawm Qhov Siab: 2m
Qhov Loj: 800 x 390 x 350mm
DELIVERY DATE:
Hauv 60 hnub tom qab tau txais cov nyiaj them poob haujlwm
DELIVERY:
Piv txwv li. Peb Cov Haujlwm ntawm Shanghai, Suav teb
TERMS OF PAYMENT:
40% los ntawm T / T ua qhov them ua ntej, qhov nyiaj tshuav ntawm 60% yuav tsum tau them ua ntej xa khoom.
OTHERS:
Kev Xeem & Kev Kawm:
Tus qauv tsim qauv ntawm lub Hoobkas, kev sib dhos thiab kev teeb tsa, kev pib ua haujlwm thiab kev cob qhia pab pawg hauv zos yuav pub dawb xwb. Tab sis tus neeg yuav khoom yuav tsum yog tus them tus nqi daim pib dav hlau mus-los, kev thauj mus los hauv zos, zaub mov thiab chaw nyob, thiab US $ 60.- / hnub / tus neeg rau cov nyiaj siv rau peb cov kws kho tshuab. Cov neeg kuaj yuav yog ob tus neeg, thiab yuav raug nqi 20 ~ 30 hnub.
Cov Kev Pabcuam:
Tus neeg yuav khoom yuav tsum npaj cov khoom siv hluav taws xob txaus, dej, pa dej thiab cov khoom siv cua compressed uas tsim nyog txuas nrog peb cov tshuab ua ntej peb cov tshuab tuaj txog.
WARRANTY:
Tus neeg muag khoom lav qhov zoo ntawm cov khoom rau 12 lub hlis txij li hnub teeb tsa. Thaum lub sijhawm lav, txhua yam teeb meem / qhov tsis ua haujlwm tshwm sim ntawm cov khoom tawv ntawm cov tshuab, tus neeg muag khoom yuav hloov cov khoom lossis xa cov kws kho tshuab mus rau tus neeg yuav khoom qhov chaw rau kev kho thiab txij nkawm ntawm DAWB. Yog tias qhov tsis ua haujlwm raug tshwm sim los ntawm kev ua haujlwm tsis ua haujlwm ntawm tus neeg yuav khoom, lossis tus neeg yuav khoom xav tau kev pab txog kev siv tshuab rau cov teeb meem ua tiav, tus neeg yuav khoom yuav tsum lav tag nrho cov nqi thiab lawv cov nyiaj pub dawb.
