Yinrich GDT300 Kab Tso Khoom Qab Zib: Kev Tsim Khoom Siv Siab Tshaj Plaws
Cov yam ntxwv ntawm cov khoom
Yinrich GDT300 Candy Depositing Line yog lub tshuab ua khoom qab zib zoo tshaj plaws uas tsim los ntawm cov chaw tsim khoom ua khoom qab zib loj. Nrog PLC/computer tswj thiab LED kov vaj huam sib luag, cov kab ntau lawm no tuaj yeem tsim tau txog li 300kgs/teev ntawm cov khoom qab zib zoo nrog kev tswj hwm meej ntawm cov xim, saj, thiab cov khoom sau. Ua los ntawm cov hlau tsis xeb SUS304, cov khoom siv no muaj cov txheej txheem txhaj tshuaj, kev ntsuas, thiab kev sib tov ua ntej, uas tso cai rau kev tsim ntau yam khoom qab zib xws li kev tso ob xim kab, kev tso ob txheej, kev sau hauv nruab nrab, thiab cov khoom qab zib tawv.
Peb ua haujlwm
Ntawm Yinrich, peb pab koj nrog cov peev xwm tsim khoom tsis siv neeg ntawm peb GDT300 Candy Depositing Line. Peb cov thev naus laus zis tshiab ua kom muaj kev tsim khoom qab zib kom raug thiab ua haujlwm tau zoo, xa cov khoom tiav zoo nrog kev yooj yim. Peb pab koj cov kev xav tau ua lag luam los ntawm kev muab cov kev daws teeb meem txhim khu kev qha thiab yooj yim rau cov neeg siv uas txhim kho koj cov txheej txheem tsim khoom. Nrog cov chaw teeb tsa kho tau thiab cov yam ntxwv tsis siv neeg, peb cov kab tso khoom qab zib ua kom yooj yim rau kev ua haujlwm thiab ua kom muaj txiaj ntsig zoo tshaj plaws. Ntseeg Yinrich los pab koj nrog cov kev daws teeb meem tshiab uas ua tau raws li koj cov kev xav tau tsim khoom qab zib, pab koj ua tiav hauv kev lag luam sib tw niaj hnub no. Cia peb pab koj nrog kev ua tau zoo thiab kev ntseeg siab.
Vim li cas ho xaiv peb
Ntawm Yinrich, peb muaj kev txaus siab los pab peb cov neeg siv khoom nrog cov kab tso khoom qab zib zoo tshaj plaws hauv kev ua lag luam. Peb cov kab tso khoom qab zib GDT300 muaj kev ua haujlwm raug thiab ua haujlwm tau zoo tshaj plaws hauv kev tsim cov khoom qab zib zoo. Nrog nws cov peev xwm ua haujlwm tsis siv neeg, lub tshuab niaj hnub no ua kom muaj kev tsim khoom zoo, txuag koj lub sijhawm thiab cov nqi zog. Txij li cov khw muag khoom qab zib me me mus rau cov chaw tsim khoom loj, peb pabcuam rau txhua lub lag luam uas tab tom nrhiav kev txhim kho lawv cov khoom qab zib. Ntseeg Yinrich kom muab cov khoom siv zoo tshaj plaws rau koj uas yuav ua rau koj cov haujlwm yooj yim dua thiab pab koj ua tau raws li qhov xav tau ntawm koj cov neeg siv khoom. Peb pabcuam los txhawb koj txoj kev vam meej.
Cov kab ua khoom no yog ib chav me me uas tuaj yeem tsim ntau yam khoom qab zib tawv hauv qab kev huv huv. Nws kuj yog ib qho khoom siv zoo tshaj plaws uas tuaj yeem tsim cov khoom zoo nrog kev txuag ob qho tib si neeg ua haujlwm thiab qhov chaw nyob.
1) PLC / computer tswj kev ua haujlwm muaj;
2) Lub vaj huam sib luag kov LED rau kev ua haujlwm yooj yim;
3) Lub peev xwm tsim khoom yog 300kgs / h (raws li 7g mono khoom qab zib ntawm 2D pwm);
4) Cov khoom noj khoom haus sib cuag yog ua los ntawm cov hlau tsis huv SUS304;
5) Xaiv tau (pawg) ntws los ntawm Frequency inverters;
6) Kev txhaj tshuaj hauv kab, kev noj tshuaj thiab kev sib tov ua ntej rau kev ntxiv cov kua dej sib npaug;
7) Cov twj tso kua mis rau kev txhaj tshuaj xim, tsw qab thiab kua qaub;
8) Ib txheej ntxiv ntawm cov tshuaj txhaj tshuaj chocolate rau kev ua cov khoom qab zib chocolate-central (xaiv tau);
9) Siv lub tshuab tswj pa dej tsis siv neeg es tsis txhob siv lub qhov dej uas tswj lub zog pa dej ruaj khov uas xa mus rau qhov ua noj.
10) "ob xim stripe depositing", "double-layered depositing", "central filling", "clear" hard candies thiab lwm yam tuaj yeem ua tau.
11) Cov pwm tuaj yeem ua raws li cov khoom qab zib uas cov neeg siv khoom muab.
- TECHNICAL SPECIFICATIONS
Qauv GDT300 Muaj peev xwm ntau lawm kg / h Max.300 Qhov siab tshaj plaws ntawm cov khoom g 7 Kev ceev ntawm stroke n / min 25~35 Kev siv dej haus kg / h
Lub zog ntawm lub zog pa Mpa200
0.2~0.6Xav tau hluav taws xob 45kw/380V Kev siv cua compressed
Lub zog cua compressed0.25mP3P/feeb
0.4-0.6 MpaCov xwm txheej xav tau rau lub kaw lus txias:
1) Chav sov (℃)
2) Av noo (%)20~25
55Qhov hnyav tag nrho Kgs 7000
