Kab Ua Khoom Siv Chocolate Lag Luam - Kev Tsim Khoom Tsis Tu Ncua
Cov kab ua pwm chocolate QJ series tuaj yeem tsim ntau yam khoom chocolate tas li. Nws yog lub tshuab PLC tswj uas muaj pwm cua sov, tso, co, txias, tshem pwm thiab lwm yam. Nws tuaj yeem tsim cov khoom chocolate zoo xws li "ob xim", "central filling", thiab cov khoom chocolate ntshiab.
Cov txiaj ntsig ntawm cov khoom
Lub Tshuab Ua Chocolate Moulding Line muaj lub tshuab tsim khoom tas mus li uas ua kom muaj txiaj ntsig zoo thiab muaj txiaj ntsig zoo. Nrog nws cov thev naus laus zis siab heev, lub tshuab no muaj peev xwm tsim ntau yam qauv thiab duab chocolate sib txawv. Nws lub interface yooj yim siv thiab kev tsim kho ruaj khov ua rau nws yog qhov kev xaiv zoo tshaj plaws rau cov lag luam uas xav ua kom lawv cov txheej txheem tsim chocolate yooj yim dua.
Peb ua haujlwm
Ntawm peb lub tuam txhab, peb pab peb cov neeg siv khoom nrog cov kab ua chocolate zoo tshaj plaws uas tsim los rau kev tsim khoom tas mus li. Peb cov tshuab ua haujlwm tau tsim los ua kom koj cov txheej txheem tsim khoom yooj yim dua thiab ua kom zoo tshaj plaws. Nrog rau kev tsom mus rau qhov tseeb thiab kev ntseeg siab, peb cov kab ua pwm yog qhov zoo tagnrho rau cov lag luam uas tab tom nrhiav kev nthuav dav lawv cov haujlwm tsim chocolate. Peb muab kev pabcuam rau cov neeg siv khoom thiab kev txhawb nqa tsis zoo tshaj plaws kom ntseeg tau tias peb cov neeg siv khoom muaj kev paub zoo txij li kev yuav khoom mus txog kev teeb tsa thiab dhau mus. Ntseeg peb kom pab koj nrog cov khoom siv zoo tshaj plaws rau koj cov kev xav tau tsim chocolate.
Vim li cas ho xaiv peb
Peb ua haujlwm los hloov pauv koj cov khoom siv chocolate nrog peb cov kab ua khoom lag luam Chocolate Moulding - Kev tsim khoom tas mus li. Peb cov tshuab tshiab yog tsim los ua kom koj cov txheej txheem tsim khoom yooj yim dua, xyuas kom meej tias cov khoom siv chocolate tas mus li thiab zoo. Nrog kev tsim kho kom raug thiab cov thev naus laus zis tshiab, peb mob siab rau kev pabcuam koj nrog cov khoom siv txhim khu kev qha thiab ua haujlwm tau zoo uas ua tau raws li qhov xav tau ntawm kev lag luam ceev ceev. Paub txog kev tsim khoom ntau ntxiv thiab kev sib xws hauv koj cov haujlwm pwm chocolate nrog peb cov kev daws teeb meem txhim khu kev qha. Ntseeg siab rau peb txoj kev cog lus los pabcuam koj nrog cov khoom siv zoo tshaj plaws uas yuav tsa koj cov peev xwm tsim khoom thiab teeb tsa koj sib txawv hauv kev ua lag luam.
kab pwm chocolate muaj cov qauv sib txawv nrog lub peev xwm sib txawv.
Daim ntawv teev cov khoom siv tseem ceeb:
| Khoom | Cov khoom siv | cov lus qhia tshwj xeeb |
| 1. | HOT WATER CIRCULATING TANK | |
| 2. | OIL MELTING OVE | RYG-30 |
| 3. | LUB TSHUAB GRINDER QAB ZIB | FTY250 |
| 4. | CONCH | JMJ50 |
| 5. | WARM KEEPING TANK | BWG500 |
| 6. | Lub Hoobkas Ua Chocolate Moulding (Ib Lub Taub Hau) (INCLUDING THE COOLING TUNNEL) | QJ150 |
| 7. | TRANSPORTING PUMP | SJB32 |
| 8. | CONTROLLE | |
| 9 | COV MOLDS | |
| 10 | TXUAS COV YEEB & COV VALVES | |
| 11 | tshuab ntim khoom | BM280 |
Cov Lus Qhia Ntxiv: COV LUS QHIA TXOG TXHUA LUB CUAB YEEJ:
1. Qhov cub roj yaj
Cov lus qhia txog kev siv:
Muaj peev xwm yaj roj: 2 x120 = 240kgs
Lub sijhawm yaj roj: 30 ~ 60 feeb
Txoj kev cua sov: Chav thiab cua sov fais fab
Kub yaj roj: 40 ~ 65C
Qhov Loj: 1300 x 650 x 1000mm
2. LUB TSHUAB GRINDER QAB ZIB:
Cov lus qhia txog kev siv:
Lub zog tsav tsheb tseem ceeb: 7.5KW
Lub zog tsav tsheb pub mis: 1.5KW
Lub zog tsav tseem ceeb: 3800 rpm
Kev tsav tsheb pub ceev: 280rpm
Qhov Loj: 1240 x 960 x 1730mm
3. CONCH
Qauv: JMJ500
Muaj peev xwm ntau tshaj plaws: 500 litres
Qhov zoo: 20 ~ 25um
Lub ntsiab tsav ceev: 33rpm
Lub sijhawm ua kom zoo: 16 ~ 22 teev
Lub zog: 15KW
Qhov Loj: 2000 x 1860 x 1250mm
Qauv: JMJ1000
Maximum peev xwm: 1000 litres
Qhov zoo: 20 ~ 25um
Lub ntsiab tsav ceev: 33rpm
Lub sijhawm ua kom zoo: 14 ~ 22 teev
Lub zog: 22KW
Qhov Loj: 2700 x 1350 x 1800mm
4. LUB TSO CIA KOM SOV
Qauv: BWG500
Muaj peev xwm ntau tshaj plaws: 500 litres
Lub zog tsav tseem ceeb: 23.5 rpm
Lub zog: 1.5 KW
Qhov Loj: dia.1000 x 1380mm
Qauv: BWG1000
Maximum peev xwm: 1000 litres
Lub zog tsav tseem ceeb: 24 rpm
Lub zog: 2.2KW
Qhov Loj: dia.1250 x 1850mm
5. CHOCALATE DEPOSITER NROG COOLING TUNNEL (ib lub taub hau version)
Qauv: QJ150 (laus)
Cov lus qhia txog kev siv:
Muaj peev xwm ntau lawm: 0.8 ~ 2.5tons / h
Lub zog: 21KW
Lub tub yees lub peev xwm: 15000 ~ 21800kcal / h
Qhov Loj: 15330 x1210 x 2200mm
Cov phaj pwm: 220 pcs
6. Twj Tso Kua Chocolate
Qauv: SJB32
Lub zog tsav tsheb: 1.5KW
Lub ntsiab tsav ceev: 127rpm
Peev Xwm: 32liter/min
Qhov Ntev Ntawm Qhov Siab: 2m
Qhov Loj: 800 x 390 x 350mm
DELIVERY DATE:
Hauv 60 hnub tom qab tau txais cov nyiaj them poob haujlwm
DELIVERY:
Piv txwv li. Peb Cov Haujlwm ntawm Shanghai, Suav teb
TERMS OF PAYMENT:
40% los ntawm T / T ua qhov them ua ntej, qhov nyiaj tshuav ntawm 60% yuav tsum tau them ua ntej xa khoom.
OTHERS:
Kev Xeem & Kev Kawm:
Tus qauv tsim qauv ntawm lub Hoobkas, kev sib dhos thiab kev teeb tsa, kev pib ua haujlwm thiab kev cob qhia pab pawg hauv zos yuav pub dawb xwb. Tab sis tus neeg yuav khoom yuav tsum yog tus them tus nqi daim pib dav hlau mus-los, kev thauj mus los hauv zos, zaub mov thiab chaw nyob, thiab US $ 60.- / hnub / tus neeg rau cov nyiaj siv rau peb cov kws kho tshuab. Cov neeg kuaj yuav yog ob tus neeg, thiab yuav raug nqi 20 ~ 30 hnub.
Cov Kev Pabcuam:
Tus neeg yuav khoom yuav tsum npaj cov khoom siv hluav taws xob txaus, dej, pa dej thiab cov khoom siv cua compressed uas tsim nyog txuas nrog peb cov tshuab ua ntej peb cov tshuab tuaj txog.
WARRANTY:
Tus neeg muag khoom lav qhov zoo ntawm cov khoom rau 12 lub hlis txij li hnub teeb tsa. Thaum lub sijhawm lav, txhua yam teeb meem / qhov tsis ua haujlwm tshwm sim rau ntawm cov khoom tawv ntawm cov tshuab, tus neeg muag khoom yuav hloov cov khoom lossis xa cov kws kho tshuab mus rau tus neeg yuav khoom qhov chaw rau kev kho thiab txij nkawm ntawm DAWB. Yog tias qhov tsis ua haujlwm raug tshwm sim los ntawm kev ua haujlwm tsis ua haujlwm ntawm tus neeg yuav khoom, lossis tus neeg yuav khoom xav tau kev pab txog kev ua haujlwm rau cov teeb meem ua tiav, tus neeg yuav khoom yuav tsum lav tag nrho cov nqi thiab lawv cov nyiaj pub dawb.
