Cov Cuab Yeej Ua Chocolate: QJ Series Moulding Line
Cov kab ua pwm chocolate QJ series tuaj yeem tsim ntau yam khoom chocolate tas li. Nws yog lub tshuab PLC tswj uas muaj pwm cua sov, tso, co, txias, tshem pwm thiab lwm yam. Nws tuaj yeem tsim cov khoom chocolate zoo xws li "ob xim", "central filling", thiab cov khoom chocolate ntshiab.
Cov txiaj ntsig ntawm cov khoom
Cov kab Moulding QJ Series muab cov cuab yeej ua chocolate tshaj lij rau cov neeg ua chocolate kom ua tau zoo thiab meej. Cov kab zoo no muaj ntau yam pwm uas tso cai rau kev hloov kho thiab kev muaj tswv yim hauv kev ua chocolate. Nrog nws cov haujlwm siab heev thiab kev tsim kho ruaj khov, QJ Series Moulding Line tau tsim los ua kom cov txheej txheem ua chocolate yooj yim dua thiab txhim kho qhov zoo ntawm koj cov chocolates.
Lub zog ntawm pab pawg
Peb lub QJ Series Moulding Line yog qhov tshwm sim ntawm ib pab neeg mob siab rau kev tsim cov cuab yeej ua chocolate zoo. Peb pab neeg lub zog yog lawv txoj kev tsim tshiab, lawv saib xyuas txhua yam, thiab lawv txoj kev cog lus los tsim cov khoom zoo tshaj plaws uas ua tau raws li qhov xav tau ntawm peb cov neeg siv khoom. Nrog ntau xyoo ntawm kev paub hauv kev lag luam, peb pab neeg ua haujlwm ua ke kom ntseeg tau tias txhua lub cuab yeej hauv peb txoj kab molding yog ua tiav thiab ua tib zoo. Ntseeg peb pab neeg txoj kev txawj ntse los coj koj cov cuab yeej ua chocolate zoo tshaj plaws uas yuav tsa koj cov khoom noj khoom haus mus rau qib tom ntej.
Lub zog tseem ceeb ntawm lub tuam txhab
Cov QJ Series Moulding Line yog qhov yuav tsum muaj rau cov kws tshaj lij chocolate thiab cov neeg nyiam ua mov ci. Nrog nws cov cuab yeej ua chocolate uas tau tsim tshwj xeeb, cov kab no tau tsim los txhawb koj cov txuj ci ua khoom qab zib mus rau qib tom ntej. Tab sis qhov ua rau cov khoom no sib txawv tiag tiag yog lub zog ntawm pab neeg tom qab nws. Peb cov engineers thiab cov neeg tsim qauv muaj peev xwm tau ua haujlwm tsis muaj zog kom ntseeg tau tias txhua lub cuab yeej hauv kab no ua tau raws li cov qauv siab tshaj plaws ntawm kev ua tau zoo thiab kev ua tau zoo. Nrog lawv cov kev txawj ntse thiab kev mob siab rau, koj tuaj yeem ntseeg siab tias QJ Series Moulding Line yuav pab koj tsim cov chocolates zoo nkauj nrog kev yooj yim thiab kev ua haujlwm txhua lub sijhawm.
kab pwm chocolate muaj cov qauv sib txawv nrog lub peev xwm sib txawv.
Daim ntawv teev cov khoom siv tseem ceeb:
| Khoom | Cov khoom siv | cov lus qhia tshwj xeeb |
| 1. | HOT WATER CIRCULATING TANK | |
| 2. | OIL MELTING OVE | RYG-30 |
| 3. | LUB TSHUAB GRINDER QAB ZIB | FTY250 |
| 4. | CONCH | JMJ50 |
| 5. | WARM KEEPING TANK | BWG500 |
| 6. | Lub Hoobkas Ua Chocolate Moulding (Ib Lub Taub Hau) (INCLUDING THE COOLING TUNNEL) | QJ150 |
| 7. | TRANSPORTING PUMP | SJB32 |
| 8. | CONTROLLE | |
| 9 | COV MOLDS | |
| 10 | TXUAS COV YEEB & COV VALVES | |
| 11 | tshuab ntim khoom | BM280 |
Cov Lus Qhia Ntxiv: COV LUS QHIA TXOG TXHUA LUB CUAB YEEJ:
1. Qhov cub roj yaj
Cov lus qhia txog kev siv:
Muaj peev xwm yaj roj: 2 x120 = 240kgs
Lub sijhawm yaj roj: 30 ~ 60 feeb
Txoj kev cua sov: Chav thiab cua sov fais fab
Kub yaj roj: 40 ~ 65C
Qhov Loj: 1300 x 650 x 1000mm
2. LUB TSHUAB GRINDER QAB ZIB:
Cov lus qhia txog kev siv:
Lub zog tsav tsheb tseem ceeb: 7.5KW
Lub zog tsav tsheb pub mis: 1.5KW
Lub zog tsav tseem ceeb: 3800 rpm
Kev tsav tsheb pub ceev: 280rpm
Qhov Loj: 1240 x 960 x 1730mm
3. CONCH
Qauv: JMJ500
Muaj peev xwm ntau tshaj plaws: 500 litres
Qhov zoo: 20 ~ 25um
Lub ntsiab tsav ceev: 33rpm
Lub sijhawm ua kom zoo: 16 ~ 22 teev
Lub zog: 15KW
Qhov Loj: 2000 x 1860 x 1250mm
Qauv: JMJ1000
Maximum peev xwm: 1000 litres
Qhov zoo: 20 ~ 25um
Lub ntsiab tsav ceev: 33rpm
Lub sijhawm ua kom zoo: 14 ~ 22 teev
Lub zog: 22KW
Qhov Loj: 2700 x 1350 x 1800mm
4. LUB TSO CIA KOM SOV
Qauv: BWG500
Muaj peev xwm ntau tshaj plaws: 500 litres
Lub zog tsav tseem ceeb: 23.5 rpm
Lub zog: 1.5 KW
Qhov Loj: dia.1000 x 1380mm
Qauv: BWG1000
Maximum peev xwm: 1000 litres
Lub zog tsav tseem ceeb: 24 rpm
Lub zog: 2.2KW
Qhov Loj: dia.1250 x 1850mm
5. CHOCALATE DEPOSITER NROG COOLING TUNNEL (ib lub taub hau version)
Qauv: QJ150 (laus)
Cov lus qhia txog kev siv:
Muaj peev xwm ntau lawm: 0.8 ~ 2.5tons / h
Lub zog: 21KW
Lub tub yees lub peev xwm: 15000 ~ 21800kcal / h
Qhov Loj: 15330 x1210 x 2200mm
Cov phaj pwm: 220 pcs
6. Twj Tso Kua Chocolate
Qauv: SJB32
Lub zog tsav tsheb: 1.5KW
Lub ntsiab tsav ceev: 127rpm
Peev Xwm: 32liter/min
Qhov Ntev Ntawm Qhov Siab: 2m
Qhov Loj: 800 x 390 x 350mm
DELIVERY DATE:
Hauv 60 hnub tom qab tau txais cov nyiaj them poob haujlwm
DELIVERY:
Piv txwv li. Peb Cov Haujlwm ntawm Shanghai, Suav teb
TERMS OF PAYMENT:
40% los ntawm T / T ua qhov them ua ntej, qhov nyiaj tshuav ntawm 60% yuav tsum tau them ua ntej xa khoom.
OTHERS:
Kev Xeem & Kev Kawm:
Tus qauv tsim qauv ntawm lub Hoobkas, kev sib dhos thiab kev teeb tsa, kev pib ua haujlwm thiab kev cob qhia pab pawg hauv zos yuav pub dawb xwb. Tab sis tus neeg yuav khoom yuav tsum yog tus them tus nqi daim pib dav hlau mus-los, kev thauj mus los hauv zos, zaub mov thiab chaw nyob, thiab US $ 60.- / hnub / tus neeg rau cov nyiaj siv rau peb cov kws kho tshuab. Cov neeg kuaj yuav yog ob tus neeg, thiab yuav raug nqi 20 ~ 30 hnub.
Cov Kev Pabcuam:
Tus neeg yuav khoom yuav tsum npaj cov khoom siv hluav taws xob txaus, dej, pa dej thiab cov khoom siv cua compressed uas tsim nyog txuas nrog peb cov tshuab ua ntej peb cov tshuab tuaj txog.
WARRANTY:
Tus neeg muag khoom lav qhov zoo ntawm cov khoom rau 12 lub hlis txij li hnub teeb tsa. Thaum lub sijhawm lav, txhua yam teeb meem / qhov tsis ua haujlwm tshwm sim rau ntawm cov khoom tawv ntawm cov tshuab, tus neeg muag khoom yuav hloov cov khoom lossis xa cov kws kho tshuab mus rau tus neeg yuav khoom qhov chaw rau kev kho thiab txij nkawm ntawm DAWB. Yog tias qhov tsis ua haujlwm raug tshwm sim los ntawm kev ua haujlwm tsis ua haujlwm ntawm tus neeg yuav khoom, lossis tus neeg yuav khoom xav tau kev pab txog kev ua haujlwm rau cov teeb meem ua tiav, tus neeg yuav khoom yuav tsum lav tag nrho cov nqi thiab lawv cov nyiaj pub dawb.
